Gemini Marine Dive 470
Spacious fully inflatable dive and work boat for carrying crew and substantial equipment. The Dive 470 combines a 1,100 kg payload with capacity for eleven people and up to 60 hp.
4.70 m length
Max. 11 persons
Max. 60 hp
Overview
About the Gemini Marine Dive 470
The Gemini Marine Dive 470 is designed to transport heavy loads, divers and their equipment. Its conventional inflatable hull form, large 550 mm tubes and broad flat deck provide generous working space in a transportable package.
The boat weighs approximately 100 kg and accepts up to 60 hp. Its 18 mm wooden floorboards are designed for heavy-duty use. As an official Gemini Marine dealer, Novi Marine advises on propulsion, boarding arrangements, lifting points and further equipment.
Key features
✓
1,100 kg payload
Designed to carry divers, crew and substantial equipment.
✓
Large buoyancy tubes
550 mm diameter tubes provide high buoyancy and stability.
✓
Heavy-duty working deck
18 mm wooden floorboards form a strong, flat platform for professional use.
✓
Capacity for eleven people
With 40 hp recommended and propulsion up to 60 hp.
Technical data
Specifications
Dimensions
Length
4.70 m
Beam
2.10 m
Tube diameter
550 mm
Weight & capacity
Unladen weight
100 kg
Maximum payload
1,100 kg
Maximum persons
11 persons
Tube compartments
5
Propulsion
Recommended power
40 hp
Maximum power
60 hp
Tubes & construction
Tube material
Hypalon 1100 dtex
Floorboards
Wood 18 mm
Standard equipment
Tubes & protection
- 1100 dtex Hypalon tubes
- Heavy-duty shark-fin rubbing strake
- Anti-hogging strip
- Internally taped seams
- Five inflation valves
Deck & equipment
- Self-draining non-slip deck
- Large flat deck area
- 18 mm wooden floorboards for heavy-duty use
- Two paddles with straps
- Righting rope
Attachment & accessories
- Stainless-steel bow eye
- Two towing points
- Double-action pump
- Repair kit
Options & configuration
Protection & construction
- 1670 dtex Hypalon upgrade
- Double skinning
- Double seam taping
- Aluminium plate protection
Access & transport
- Lifting points and lifting slings
- Boarding ladder
- Rowlocks and oars
- Transom supports
- Boat cover
- Bow bag
- Bow dodger
In pictures
Gemini Marine Dive 470 gallery
Interested in the Gemini Dive 470?
Tell us how you plan to use the Dive 470. We will advise on engines, deck layout and equipment and propose a configuration that fits your operation.
