Rhino Marine Slab-Sided Bulwark
Rhino Marine 600SB
Robust HDPE workboat with high bulwarks, generous working space and a medium-V hull. Built for dive support, survey, personnel transfer and equipment transport.
5.89 m length
Max. 7 persons
Rec. max. 150 hp
Overview
About the Rhino Marine 600SB
The Rhino Marine 600SB is designed around working space, payload and stability. Its medium-V hull and slab-sided bulwarks free up deck space without the broad sponsons used on other Rhino designs. This makes the compact HDPE workboat well suited to dive support, survey, personnel transfer and equipment transport.
The 600SB is available with an open deck and tiller steering or a console and jockey seat. Bow transfer rails, heavy-duty fenders, attachment points and rubber deck matting support day-to-day operations. As an official Rhino Marine dealer, Novi Marine advises on propulsion, deck layout and equipment for your application.
Key features
✓
Usable working space
Slab-sided bulwarks rather than broad sponsons make room for crew, equipment and operations.
✓
Medium-V HDPE hull
A robust working platform designed with an emphasis on payload and stability.
✓
Practical bow and lifting points
Bow transfer rails, heavy-duty fenders and four-point lifting provisions support professional operations.
✓
Open deck or console
Choose tiller steering or a console version with a jockey seat and hydraulic steering.
Technical data
Specifications
Dimensions
Length
5.89 m
Beam
2.28 m
Light draught
0.25 m
Height · handrail to keel
2.215 m
Weight & capacity
Lightship weight
1,260 kg
Max. persons
7 persons
Recommended max. payload · including engines
2,200 kg
Propulsion
Recommended max. power
150 hp
Engine configuration
Single / twin outboard
Fuel
Petrol / diesel
Recommended max. speed
30 kn
Construction & transport
Hull
Medium-V
Material
HDPE
ISO design category
C
Container transport
20 ft
Application
Workboat / tender
Standard equipment
Hull & deck
- Medium-V HDPE hull
- Bulwark seating and upstand
- Aluminium stern compartment hatch
- Bow anchor compartment and storage hatches
- Work-safe rubber deck matting
Protection & fittings
- Heavy-duty bow D-fenders
- Bow transfer handrails
- Heavy-duty forward and aft bollards
- Bow towing pad-eye
- Cleats and attachment points
- Four lifting pad-eyes
- Four-point webbed lifting slings and shackles
Console version
- HDPE console with coxswain lean post
- Jockey seat
- Electrical installation
- Hydraulic steering
- Marine VHF radio
Options & configuration
Deck layout
- Open deck with tiller steering
- Console controls with jockey seat
- Canopy and seating options
Propulsion
- Single or twin outboard engines
- Petrol or diesel propulsion
- Yanmar D36/D40 diesel outboard engines
In pictures
Rhino Marine 600SB Gallery
Interested in the Rhino Marine 600SB?
Tell us how you plan to use the 600SB. We will advise on engines, deck layout and equipment and propose a configuration that fits your operation.
